VM II III IV Axpert Solar System off grid inverter
-
MODEL Axpert VM II TWIN 3.6K Axpert VM II TWIN 5.6K RATED POWER 3600VA/3600W 5600VA/5600W INPUT Voltage 230 VAC Selectable Voltage Range 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) Frequency Range 50 Hz/60 Hz (Auto sensing) OUTPUT AC Voltage Regulation (Batt. Mode) 230VAC ± 5% Surge Power 7200VA 11200VA Efficiency (Peak) 93% Transfer Time 10 ms (For Personal Computers) 20 ms (For Home Appliances) Waveform Pure sine wave Dual Outputs Yes BATTERY Battery Voltage 24 VDC 48 VDC Floating Charge Voltage 27 VDC 54 VDC Overcharge Protection 33 VDC 63 VDC SOLAR CHARGER & AC CHARGER Solar Charger type MPPT Maximum PV Array Open Circuit Voltage 500 VDC Maximum PV Array Power 5000W 6000W Maximum PV Input Current 27A 27A MPP Range @ Operating Voltage 60-450 VDC 60-450 VDC Maximum Solar Charge Current 120A 120A Maximum AC Charge Current 100A 100A Maximum Charge Current 120A 120A PHYSICAL Dimension, D x W x H (mm) 107 x 322.6 x 420.3 Net Weight (kgs) 9.5 10.5 Communication Interface USB/RS-232 OPERATING ENVIRONMENT Humidity 5% to 95% Relative Humidity(Non-condensing) Operating Temperature -10°C to 50°C Storage Temperature -15°C to 60°C Product specifications are subject to change without further notice
MODEL Axpert VM III TWIN 4K Axpert VM III TWIN 6K RATED POWER 4000VA/4000W 6000VA/6000W INPUT Voltage 230 VAC Selectable Voltage Range 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) Frequency Range 50 Hz/60 Hz (Auto sensing) OUTPUT AC Voltage Regulation (Batt. Mode) 230VAC ± 10% Surge Power 8000VA 12000VA Efficiency (Peak) 90% ~ 93% Transfer Time 10 ms (For Personal Computers) 20 ms (For Home Appliances) Waveform Pure sine wave BATTERY Battery Voltage 24 VDC 48 VDC Floating Charge Voltage 27 VDC 54 VDC Overcharge Protection 33 VDC 63 VDC SOLAR CHARGER & AC CHARGER Solar Charger type MPPT Maximum PV Array Power 5000W 6000W MPP Range @ Operating Voltage 60 ~ 450 VDC 60 ~ 450 VDC Maximum PV Array Open Circuit Voltage 500 VDC 500 VDC Maximum PV Input Current 27A Maximum Solar Charge Current 120A 120A Maximum AC Charge Current 100A 100A Maximum Charge Current 120A 120A PHYSICAL Dimension, D x W x H (mm) 115 x 300 x 435 Net Weight (kgs) 9 10 Communication Interface USB/RS232/RS485/WiFi/Dry-contact OPERATING ENVIRONMENT Humidity 5% to 95% Relative Humidity (Non-condensing) Operating Temperature -10°C to 50°C Storage Temperature -15°C to 60°C
Product specifications are subject to change without further notice. Chasing Radiates your selected color upward from the bottom of the ring MODEL Axpert VM 4 3600-24 Axpert VM 4 5600-48 RATED POWER 3600VA/3600W 5600VA/5600W INPUT Voltage 230 VAC Selectable Voltage Range 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) Frequency Range 50 Hz/60 Hz (Auto sensing) OUTPUT AC Voltage Regulation (Batt. Mode) 230 VAC ± 5% Surge Power 7200VA 11200VA Efficiency (Peak) 90% ~ 93% Transfer Time 15 ms (For Personal Computers) ; 20 ms (For Home Appliances) Waveform Pure sine wave BATTERY Battery Voltage 24 VDC 48 VDC Floating Charge Voltage 27 VDC 54 VDC Overcharge Protection 33 VDC 63 VDC SOLAR CHARGER & AC CHARGER Solar Charger Type MPPT MPPT Maximum PV Array Power 4000W 6000 W MPPT Range @ Operating Voltage 120 ~ 450 VDC Maximum PV Array Open Circuit Voltage 500 VDC Maxmum Solar Charge Current 120 A 120 A Maximum AC Charge Current 100 A 100 A Maximum Charge Current 120 A 120 A PHYSICAL Dimension, D x W x H (mm) 119 x 313.6 x 422.8 Net Weight (kgs) 10.0 12.0 Communication Interface USB/RS232/RS485/WiFi/Dry-contact OPERATING ENVIRONMENT Humidity 5% to 95% Relative Humidity(Non-condensing) Operating Temperature -10°C to 50°C Storage Temperature -15°C to 60°C
MODEL Axpert VM 4 TWIN 4K Axpert VM 4 TWIN 6K RATED POWER 4000VA/4000W 6000VA/6000W INPUT Voltage 230 VAC Selectable Voltage Range 170-280 VAC (For Personal Computers) 90-280 VAC (For Home Appliances) Frequency Range 50 Hz/60 Hz (Auto sensing) OUTPUT AC Voltage Regulation (Batt. Mode) 230VAC ± 10% Surge Power 8000VA 12000VA Efficiency (Peak) 90% ~ 93% Transfer Time 10 ms (For Personal Computers) 20 ms (For Home Appliances) Waveform Pure sine wave BATTERY Battery Voltage 24 VDC 48 VDC Floating Charge Voltage 27 VDC 54 VDC Overcharge Protection 33 VDC 63 VDC SOLAR CHARGER & AC CHARGER Solar Charger type MPPT Maximum PV Array Power 5000W 6000W MPP Range @ Operating Voltage 60 ~ 450 VDC 60 ~ 450 VDC Maximum PV Array Open Circuit Voltage 500 VDC 500 VDC Maximum PV Input Current 27A Maximum Solar Charge Current 120A 120A Maximum AC Charge Current 100A 100A Maximum Charge Current 120A 120A PHYSICAL Dimension, D x W x H (mm) 119 x 313.6 x 457.5 Net Weight (kgs) 10 12 Communication Interface USB/RS232/RS485/WiFi/Dry-contact OPERATING ENVIRONMENT Humidity 5% to 95% Relative Humidity (Non-condensing) Operating Temperature -10°C to 50°C Storage Temperature -15°C to 60°C About us
FAQ
Q1. Are you a factory or trading company?
We have two modern factory. We have 120 factory workers and 10 of them are quality control and engineer guys. Welcome to visit our factory.Q2. Is Your products the lowest price?
GT take the quality into consideration prior. The price is based on the quality level and the order quantity. We have different quality level products for buyers option and discount is available from us when the order is big.Q3. All products have a warranty?
Yes, we supply 1 to 25 years warranty for our products. You will be satisfied with our quality.Q4. What is the transportation?
By air, by Sea, by Express, by Train, all are ok to us.Q5. If the goods in transit damage, how to do?
First of all, we will use stable packing, the possibility of the goods damaged during the shipping is low. If the goods is damaged during shipping and we covered the insurance, we will claim the insurance company and let them cover the loss. If there is no insurance cover, we will claim the shipping company and some times, we cover the loss of the goods for client.Q6. Can we design packaging?
Yes, but there is with quantity limitation. We will make the packing free for the client, and if less , we can talk, the package is free or little money will be charged.Q7. Can we add our logo on products?
Yes, there are several ways to do this. We can put the label of your logo on the products or make the silk print of your logo on the products. It is free.Q8. can we customize product?
OEM and ODM are welcomed from GT. We have rich experiences in this area.
uninterruptible power support in a single package. The comprehensive LCD display offers user-configurable
and easy-accessible button operations such as battery charging current, AC or solar charging priority, and
acceptable input voltage based on different applications.
